- 品牌：SD
- 线长：可定制
- 工作电压：5V
- 工作电流：300MA
- 货号：3-1200
- 产品规格：详询客服*20*详询客服*详询客服
- 插入损耗：20
- 规格：20-105SDG系列
- 调整频差：0.002
Main products：Ultrasound piezoelectricceramics frequency components、Medical microporous atomizing slices、High frequency atomizing slices、Power ceramic slices、High precision laser microporous processing
采用激光设备打孔技术，2-3孔径，中位径粒在2-5um，可以顺畅出雾而不停顿，没有顿挫感。
我司的医疗网格MESH雾化片具有以下特点：
◎ 颗粒：中位径粒在2-5um 所占比值达到75-80%。
◎ 雾化速率（裸测，无负载） ＞0.30~0.35 ml/min 以上。
◎ 雾化过程中无积水，喷雾不停顿，雾化稳定。
◎ 功耗小于1W,雾化片和电池寿命延长数倍。
◎ 频率适配性佳。频率常用的规格为108KHZ，111KHZ.（可定制）。
◎ 钢片和陶瓷片经过处理，抗氧化，抗腐蚀耐酸碱，不电解发黑。
◎ 雾化片寿命在正常工作下为3000h,强化测试为为1000h以上。
◎尺寸保证：陶瓷片和钢片一样尺寸大小16.00-0.05mm之内，不会造成组装困难。
◎ 钢片表面和陶瓷表面不溢胶，不歪斜，无鼓包，胶合良好平整性好。
◎ 微孔无盲孔，通透率在99.9%。孔径大致一致性好，误差≤0.5um。
1.Particles: the ratio of 2-5um to 75-80% of the median diameter particles.
2.The atomization rate (bare measurement, no load) is above 0.30~0.35 ml/min.
3.There is no water in the process of atomization, the atomization does not stop, and the atomization is stable.
4.Power consumption is less than 1W, atomizing sheet and battery life are extended several times.
5.Good frequency adaptability. The most commonly used frequency specifications are 108KHZ, 111KHZ. (customizable)
6.Steel sheet and ceramic sheet are treated to resist oxidation, corrosion, acid and alkali, no electrolytic blackening.
7.The service life of the atomizing sheet is 3000h under normal operation, and the intensive test is more than 1000h.
8.Size guarantee: the size of ceramic and steel plates is within16.00-0.05mm, which will not cause assembly difficulties.
9.The surface of steel sheet and ceramic does not overflow with glue, does not skew, does not bulge, has good gluing and flatness.
10.The micropore has no blind hole and the permeability is 99.9%. The aperture is generally consistent and the error is≤0.5um.
公司通过GB/T19001-2016/ISO9001:2015质量体系认证，RoHS认证报告，公司所有产品全部严格按照产品工艺管控流程制作，精益求精，不断。
The company has passed the GB/ T19001-2016 / ISO9001:2015 quality system certification and RoHS certification report. All the products of the company are made in strict accordance with the product process control .
